SBF Burgmans Cafe 2008 - K1 to K7

[contacted]

Made a trip down to Guan Hoe @ 120 Rangoon Road to view the Burgman 400 K7. Mr Ang was present to let me sit on the bike and point out some key features. Weird thing that I was advised to purchase the bikes from shops (Suzuki Dealers) out there.



Front Cover:

http://www.picturesky.com/albums/userpics/11896/Brochure01.jpg



Random Page:

http://www.picturesky.com/albums/userpics/11896/Brochure02.jpg



Random Page:

http://www.picturesky.com/albums/userpics/11896/Brochure03.jpg



Colour choices: Metallic Oort Gray, Pearl Nebular Black, Candy Indy Blue, Candy Somoma Red

http://www.picturesky.com/albums/userpics/11896/Brochure04.jpg



I was told that they only had Gray and Blue.

[Arcfire]

Originally posted by Terrible One@January 30, 2007 06:21 pm

And audio system!! So u can go to the beach with ur GF and play the Little umbrella song.. So romantic



Haha......Neve liked the idea of an audio system....... rainy days still have to cover up.....



I prefer to spend my money on upgrades to the bike to improve its handling etc

[william_liu]

Same same!

[spy622]

Originally posted by Arcfire@January 26, 2007 03:22 pm

William check out this one....



CliCk

I hav seen this a long time ago...if some1 is to bring it in for runners then it will be another big craze again

[william_liu]

Originally posted by Arcfire@January 31, 2007 10:40 am

Ok.... I oso no $$ to buy now Next time we buy the Mivv one together when we save enuff.... haha



Okay, onz!



Oh, I just thought of something..... Remember about the oil loss problem? I just thought of something which might be possible. What if we were to connect the breathe tube to a bottle with an inlet at the bottom and an outlet at the top. In between in the bottle we place a wire mesh similar to the one in the crankcase or simply steel wool and the outlet goes to the airbox. That way, the vapour condenses on the wool an drips to the bottom of the bottle which in turn flows back to the engine when the engine stops running. Steel wool would unlikely flake thus no worries about particles going into the engine. I attached a diagram to illustrate it.



Yup, it should work... but how to get such a bottle? It must be able to withstand the hot oil, and be air-tight to work properly.

[Terrible One]

Ok here's a few example..



http://www.spi-moto.com/ape/ape_image/oil_catch_tank.jpg



http://www1.odn.ne.jp/~cal55110/photo/aprilia_parts/body/oil_catch_tank.JPG

Aprillia RSV



http://www.babyface.co.jp/yzf250oilcatchtank1.jpg

Yamaha YZ250



http://www.uniqueautosports.com/pricelists/General/Skyline%20parts/gtstcatchtank.jpg

The POSH oil catch tank look a little like this.. With 3 holes.. One for the crank case outlet, one for the EG filler and one to the airbox/air filter.. If u wanna do it like the setup on the RSV or YZ jus cover the other hole.. I know how to do, just that I dunno how to remove the bloody tub under my seat!!! Arrgh

[Terrible One]

Finally found the pic of it..



http://i145.photobucket.com/albums/r226/wingyap/P1050883-2.jpg



Can buy from here.. How much I dunno.. Inside empty.. Haha.. Really.. Some car owners actually paid hundred for these..

[Arcfire]

Well, if its empty, it doesn't really serve any purpose does it? there's no filtration involved meaning its just like a longer pipe tats all....

[william_liu]

Originally posted by Terrible One@January 31, 2007 01:39 pm

Finally found the pic of it..



http://i145.photobucket.com/albums/r226/wingyap/P1050883-2.jpg



Can buy from here.. How much I dunno.. Inside empty.. Haha.. Really.. Some car owners actually paid hundred for these..

Looks good... but dunno how big this is....



Anyway, the black plastic under your seat is removable by just taking out the two plastic fasteners at the sides.

[william_liu]

Originally posted by Arcfire@January 31, 2007 01:50 pm

Well, if its empty, it doesn't really serve any purpose does it? there's no filtration involved meaning its just like a longer pipe tats all....

Think the theory is the oil vapour will 'condense' when reaching the cooler metal?

[Arcfire]

Originally posted by william_liu@January 31, 2007 06:08 pm

Think the theory is the oil vapour will 'condense' when reaching the cooler metal?

Yeah but if the bottle is going to be near the engine then its not going to be very much cooler anyway...... Also, the vapour is not just limited to travel at the sides of the bottle. It can also travel at the centre where the colder metal has no effect.



But i was thinking if there was something inside to increase the surface area of contact between the vapour and some metal part then the condensation effect will be better.

[william_liu]

Best is to have a flat piece of metal, with small holes inside in the middle.... or maybe a few layers.

[Arcfire]

Originally posted by william_liu@February 01, 2007 11:56 am

Best is to have a flat piece of metal, with small holes inside in the middle.... or maybe a few layers.

That is an idea, but how to find a bottle like that? Even if SK can do that its not gonna be cheap.....

[william_liu]

Take existing oil catch tank and modify? Cut open, weld in the plates then weld back together...

[Arcfire]

Originally posted by william_liu@February 01, 2007 04:47 pm

Take existing oil catch tank and modify? Cut open, weld in the plates then weld back together...

Wahhhhh... big project sia..... machiam like technical workshop lesson..... hahahah..... mabbe if i free and my mech nothing to do den i ask him to try.... i'll probably check with him on the feasibility of doing such a thing.



hi,guys!some help needed.



wats the market price for a EFI burgman 400 now?

is 7k a gd buy?

wats the common problems of this bike?

wats the fuel consumtion like?



tks



Depends on which year you are getting. The K3 was ard that price when i bought it last year. But you probably can get it at a cheaper price. Was quoted 7k for a K2 by GHC tat time.....



Look ard more. You can probably get a better deal. Gd luck!

[ah_huats]

Originally posted by echris108@February 01, 2007 05:21 pm

hi,guys!some help needed.



wats the market price for a EFI burgman 400 now?

is 7k a gd buy?

wats the common problems of this bike?

wats the fuel consumtion like?



tks

Market price shld be $6K +-



Fuel consumption depends on rider.

I average 30~31 km/l nowadays... 340Km on 11L

The worst case for a burgy shld be 24~25 which isnt that bad.



Common major problem, Not that i know of other den EO disappearing ...

[Arcfire]

Originally posted by william_liu@February 01, 2007 04:47 pm

Take existing oil catch tank and modify? Cut open, weld in the plates then weld back together...

After some discussion with my mech i think we may have come up with a solution. Our intention is to use a brake fluid reservoir as the oil tank catch. It can be opened and is airtight. It also already has an inlet at the bottom which is needed. The only thing to do is to drill a hole somewhere at the top of the reservoir and place the tub in and epoxy the gap to make it air tight. Den add in steel wool into the reservoir and voila!



Think this might work?

[william_liu]

Arcfire: Sounds like it might just work! but the area is rather small.... and it may be cheap to use an automotive fuel filter as some people have done in the BurgmanUSA forum previously.



Anyway I took out my K&N to wash, and also to see if that helps improve the oil usage problem a bit... now running with oil foam filter, actually I quite like the reduction in noise...



Will monitor 1st for 1 or 2 weeks before deciding whether to put the K&N back.

[Arcfire]

Originally posted by william_liu@February 02, 2007 10:05 am

Arcfire: Sounds like it might just work! but the area is rather small.... and it may be cheap to use an automotive fuel filter as some people have done in the BurgmanUSA forum previously.



Anyway I took out my K&N to wash, and also to see if that helps improve the oil usage problem a bit... now running with oil foam filter, actually I quite like the reduction in noise...



Will monitor 1st for 1 or 2 weeks before deciding whether to put the K&N back.

I'm intending to place the reservoir on the frame of the bike inside the fairing somewhere at the burgman wordings.... so that the bottle will be at a higher level than the breather outlet. Only problem is, i won't be able to see the reservoir.

[Edwin D]

Originally posted by contacted@February 02, 2007 10:24 am

Yo folks, as earlier mentioned I already went to view the bike at the showroom the other day. I'm still puzzled over the fact that it was best not to buy the bike from the showroom itself but rather at Suzuki's dealers.



Can anybody advise why? PM me if its 'confidential' information. Many thanks guys

Distributor cannot sell at a lower price than the dealers otherwise no dealer will be willing to sell their bikes for them. Does this explain it? Standard industry practice. Of cos there are exceptions...

[william_liu]

Think it's not... cos when I changed my breather tube it was just a normal pipe without any such attachment...



Really want to solve this engine oil missing issue...

[Terrible One]

Actually our original breather tube inside got one plastic valve.. Saw one at GHC the other day, that bike overhual so I took a peek..

[Arcfire]

Originally posted by william_liu@February 09, 2007 12:09 am

wah! So the parts came? How is it? And what's the damage??

Yes... after so long they finally arrived..... and you would never guess how much everything cost me.....



And the interesting thing was, my mech asked around other mechs and they said there have been cases of the washer breaking off as it was bloody filmsy. If you saw the piece of junk you would think so too. And cause it sits at the counter-balancer gear, it gets compressed and released everytime you rev your engine, thus over time it will break, like any other thin piece of metal.



So what other mechs have told him was that once broken, they don't replace it. They simply leave out the washer. The only thing would be that the counter-balancer gear would be abit lose but other than that not observable effects. How true is that i have no idea. So if any of you guys are going for your valve clearance or opening up your crankcase do take a look at it n see if its still there n update us on its condition, whether its really that easy to break off....

[william_liu]

Valve clearance? Don't think I'll be doing that anytime soon... unless the engine really starts to behave real weirdly.

[atlantic]

Originally posted by ah_huats@February 07, 2007 09:16 pm

I hv waited for almost 6 mths for my parts and still waiting ...

Starting to wonder if 'they' got order it for me in the first place or not...

I was so fed-up with their slow process of ordering, Now I ordered directly from US.

So much faster, Its take less then 7 days to reach my door......
