[Group] SBF Yamaha Spark Z & X

[ZoRoM]

To All Riders out there, Happy New Year - 2008.



All 2007 post had been moved to SBF Cubs Community Depository

* KIV - SBF Yamaha Spark Z & X Portal 2007





Best wishes true out the year.



Ride Safe.





Regards,

ZoRoM

SBF Cubs Moderator

http://www.singaporebikes.com

~~~~~~~~~~~~~~~~~~~~~~~~~~~

Edited May 3, 2012 by ZoRoM

[gunshead]

31/12/07 fill in 3.24 litre at 61961 Jb caltex at RM6.20

2/1/08 fill in 4.15 litre at 62145 spore shell

so roughly 1 litre i am getting 56km average urban 100km/h



with new denso iridium , air filter and redex petrol treatment and fully sythetic oil

[nk3371]

Got new room already...

[gunshead]

nk3371 ,



where u get the yamaha lagenda banner

nicely done

u draw?

[CasToLeRo]

lets have power.how do we get more power in this machine.?/



any info?

[BatmanV]

I love the banner of nk3371 too.

[helL-rider]

me 3



YAMAHAsparkZlagendajupiterv:thumb:

[nk3371]

nk3371 ,



where u get the yamaha lagenda banner

nicely done

u draw?



Haha..thanks...

I draw it using Photoshop...

It was a cup prix images...then I've added the headlamp and my bike's color scheme...

[gunshead]

meter 62858



today i changed full synthetic oil - DELPHI brand 10w-50

and then the mechanic said my exhaust from block has hole and leaking smoke

this means

fuel intake high and the 'pop' sound arise and morning starting problem



then he retighten the exhaust nuts.

[gunshead]

gentle reminder



check

1. bearings of front and rear wheels



2. bolts and nuts of upper block engines



3. exhaust nuts tighten



4. change air filter



change them if necessary

[gunshead]

meter 634XX

changed front wheel bearing

koyo brand

$28

at serangoon road

19/1/08

[ZoRoM]

Location: Thompson prata hse

Time: 10pm onwards

Date: 25 / 01 / 08 (Friday)

Event: TC session la kopi





More rider list will be continue at SBF Yamaha X-1r 135 Portal 2008





Anyone interested? jus come if free. last min can oso come. after work one oso come. at home slack bored oso come. pls show some support cox 1st time org



Bro, xiangkia first time organise outing for all the riders.



If you guys or gals are free on tat day show some supports and drop by to had a drinks together.



[gunshead]

I just came back from Ipoh today 5am

missed the TT kopi session

ai yaaaaa

[gunshead]

Anyone here using duro front tyre tubeless?

[maxbiaggi]

hi everyone .

jus change my air filter today.brought from autocycle

and also change mi plug to denso iridium

engine really feel smoother.pickup abit faster

i hav to thanks bro gunshead for the recom!!



nxt stop maybe revtec..............any feedback?

[gunshead]

meter 65202

16/2/08



changed



1. engine oil

2. air filter

3. brake fluid dot 4

4. tighten valve tappet

[gunshead]

coming soon to do on my bike

now very noise upper block engine parts and clutch housing



clutch plate

&

two tyres

[nk3371]

Latest modification on my Lagenda...

Hooked up my Lagenda with this big bore kit...

http://img81.imageshack.us/img81/4974/16022008212iu6.jpg

http://img257.imageshack.us/img257/7783/16022008215hp6.jpg



That is a 57mm bore block with 62mm sleeve...



So now my Lagenda's engine capacity is



Bore x Stroke = 57 x 54mm



Do the math and you get 137.8cc



Now my engine capacity is bigger than the 135LC's engine...



Also there is some major modification was done to my bike lately...

- Machined the gearbox set.

- Tweaked the auto clutch.

- Machined the crankcase hole to fit the big bore block.

- Installed Mikuni TS125 carburetor.



Now still running in the engine. Can't test is yet.

[gunshead]

abang lagenda,



kau memang terlampau POWER.....rocket

[gunshead]

hi all,



i went to JB changed black oil semi synthetic castrol 15w-40 on 5/3/08

then i asked the foreman why i hear extra sound

although i know but simply testing the foreman



he is correct

he said my boosh for clutch plate housing worn out

that's why got 'klac klac klac ' sound



ok.

next time i go and repair

[gunshead]

I have summarized 16 items to repair on my bike

now my bike has 67000 km mileage



i will be doing in this shop



call 607-2355800 for Ah keong.

location: no.85, jalan skudai kiri, batu 4 1/2.

[gunshead]

Yamaha Spark Z

Meter 67149

AG Motor, Jalan Skudai

Mechanic: Mr. Keong

13 March 2008

11am till 5pm



1. OSRAM halogen bulb front head lamp RM10 x 2 =RM20

OSRAM is better then FUJI halogen. It has balance

current flow for front and rear light.

2. Flush Brake Fluid DOT 4 , cleaned brake fluid container

3. DENSO Iridium Plug, bought in Rowell Road, Spore =SGD17

4. MAXXIS front tyre tubeless Made in Taiwan =RM70 http://www.maxxis.com/contact_us/locations.asp

excellent tyre 70/80-17 good cornering and treads

Switched my existing front Michelin to rear wheel

as rear Michelin worn out

5. Handgrip – changed to original RXZ catalyzer / Yamaha Lagenda =RM10

6. Engine oil (15w-50)

7. Chain drive adjust and sprayed Putoline GP1 chain jelly

8. Tighten all nuts / bolts

9. Rewiring for high beam light in meter panel. Add another wire wire for looping.

10. FCC brand – clutch plate 5 pieces RM13 x 5 =RM65

11. DAISO brand – clutch damper set – boosh rubber =RM20

12. Clutch housing O-Ring rubber =RM6

13. NOBORU brand – gasket =RM6

14. Service labour charge for clutch replacement =RM15

I witnessned tedious process to replace boosh rubber inside housing

15. Miscellaneous labour charge =RM5

16. Front wheel – changed tyre nut (air nut), the original rubber broke =RM5

17. Throttle cable insert oil inside. Put oil on the handle bar for throttle to work smoothly. Need to do this every 6 months because water always make rusty.

Total =RM222



wash bike = RM6



Confirmed 13/3/08 meter 67149

He said Suzuki has best design for engine and gearbox

Honda is good for long term lasting

But Yamaha always fails at clutch housing cutch damper worn out and crankshaft bearing loosen and not fit. The symptom is very loud noise while riding

My bike is good condition but ‘sayang’ the bearing of crankshaft has loosen. He showed me by opening the cover (big nut) at left hand side gear box and showed the shaking of bearing. It has to be done during overhaul and sent to factory for fitting.

Anyway, I plan to do some other time in future.



I plan to use Pennzoil engine oil in future

http://www.pennzoil.com.my/products.php?categoryid=1

[nk3371]

Tested my bike last week...

Clocked 160km/h on first 700m...Still slow..

need to make it faster..

gonna install racing camshaft and change the sprocket ratio...

also gonna resetting the carb main jet and pilot jet...

[gunshead]

18/3/08 - 4.32litre RM8.30 meter =67605

19/3/08 - 67780 finished one whole tank



so roughly with constant speed of 110km/h i got 175km



20/3/08 67780, 3.20litre $6.67

[dying]

hello. i'm taking out my spark z this sat. any things to specially look out for in the bike? anything to pay special attention to? is it minimal maintenance? looking forwards to replies! =)
